Sistem POS all-in-one MAZIC G-1500, POSBANK

SPECIFICATII

SISTEM

Procesoare

Intel® Celeron® Processor J3455 (2M Cache, up to 2.3 GHz, 4 Cores)

Chipset

7200U/7100U/3965U Intel® Kaby Lake

J3455 Intel® Apollo Lake

Memorie

7200U/7100U/3965U 4GB Standard, DDR4 2133 MT/s, Socket 1 x SODIMM (Max. 16GB)

J3455 4GB Standard, DDR3L 1600 MT/s, Socket 1 x SODIMM

Capacitate

NVME M.2 128G

RAID

7200U/7100U RAID 0,1 (SATA Only)

Sistem de Operare

Windows 10 IoT Enterprise

Audio

HD Audio Codec

DISPLAY

Tip

15" TFT LCD, LED Backlight

Rezolutie

1024 x 768

Luminozitate

300 cd/m² (typ.)

Touchscreen

Projected Capacitive Touch, AF

INTERFATA

Display

1 x Display port (USB-C)

USB

5 (Rear 5, USB 3.0 x 2,USB 2.0 x 2, USB C type x 1)

3 (Reserved for MSR, SCR, i-Button/Touch Controller)

Serial

2 (COM 1 reserved MSR/SCR, TX/RX only)

(COM2 reserved CDP, TX/RX only)

Port Sertar de bani

1 x RJ-11 (Integrated circuit GPIO)

LAN

1 x Gigabit Ethernet, RJ-45

Audio

1 x Line-out

Extension Slot

M.2 for Wi-Fi/BT

ALIMENTARE

Sursa alimentare

Adaptor 12V, 5A(C-Type Plug) / 24V, 6.35A (3Pin DIN Plug) (I/O BOX Option)

ALTE SPECIFICATII:

Temperatura de operare

0 ℃ ~ 60 ℃ at 10% to 90% Humidity

Temperatura de depozitare

-20 ℃ ~ 80 ℃ at 10% to 90% Humidity

Dimensiuni (W x H x D)

346 x 385 x 240 (mm), 13.6 x 15.2 x 9.4(in)

Greutate neta

6.2 kg

Certificari

CE, FCC, KC

Culoare

Matte Dark Black

OPTIONALE & PERIFERICE

Display secundar

9.7" (1024 x 768), 13.3" (1920 x 1080) LCD Display, Optional Touchscreen

13.3" (1920 x 1080)

Afisaj client

VFD, 20 Columns x 2 Lines

I/O Expansion

Suporta I/O Expansion Box

4 x COM (2 x D-sub/COM3/COM4, 2 x RJ-45/COM5/COM6)

1 x HDMI

1 x Gigabit Ethernet, RJ-45

2 x USB 3.0

4 x USB 2.0

1 x Cash Drawer Port (RJ-11 6pins)

2 x Powered USB (12V/24V)

Capacitate

NVME M.2 128G

Cititor benzi magnetice

In conformitate cu ISO 7811, Suporta 1 & 2 & 3 Track

Cititor smart carduri

EMV Level 1, 2

Dallas

Dallas i-button Reader

Amprenta digitala

Da

Camera

5M USB Interface (Internal) (Factory Option)

Kit montare pe perete

VESA-Compatible, 100 x 100(mm)

Boxe

2 x 0.7W (Stereo) (Factory Option)

WiFi

Combo Module, M.2 (Factory Option)

Bluetooth

Combo Module, M.2 (Factory Option)

Caracteristici
