| Afișaj | Display | |
| Afișaj operator | 15" TFT LCD, 1024x768px, |
| Touch Screen | True-flat PCAP touch with multi-touch support (IP65 on front panel) |
| Contrast | - |
| Luminozitate | - |
| Raport display | - |
| Afișaj client | Line Display (optional): 2 x 20 rear-mount VFD/LCD customer line display, 7-inch color LCD graphical customer line display; POS Monitor (optional): Non-touch TFT LCD: 7-inch/9.7-inch/12.1-inch/14-inch/15-inch,PCAP touch TFT LCD: 9.7-inch/14-inch/15-inch, Resistive touch TFT LCD: 15-inch. |
| Procesor | |
| Model procesor | Kaby lake Core i5-7360U |
| Frecventa de lucru (Ghz) | 2.30-3.60 |
| Cache (Mb) | 4 |
| Memorie operativa | |
| Tip memorie operativa | SO-DIMM DDR4 |
| Volum memorie operativa (Gb) | 8 |
| Volumul max. memorie operativa (Gb) | 16 |
| Memorie nevolatilă | |
| Tip memorie nevolatilă | 1 x M.2 connector [SATA Signal Only] + 1x SATA, w/ power connector (SATA port is available through service window) |
| Volum memorie nevolatilă (Gb) | 256 |
| Audio | |
| Puterea sumară (W) | 1xBuzzer; Internal 1x2W speaker (optional) |
| Comunicaţii fără fir | |
| Bluetooth | - |
| WiFi | M.2 WiF (optional) |
| 4G LTE | - |
| Interfețe și porturi | |
| Display Port | - |
| Ethernet | 1xLAN RJ-45 (1000Mbps) |
| HDMI | - |
| Mufa alimentare | + |
| RS232 | 3 x RJ50, 5V/12V support on all COM ports |
| USB | 5 x (2 x USB 3.0 + 3 x USB 2.0); Powered USB Port: Optional 24V x 1 + 12V x 3 via GEN8 base |
| VGA | 1 x VGA (12V support for Posiflex monitors) |
| Sursă de alimentare | |
| Tensiunea de alimentare | 100-240V AC, 50-60Hz |
| Adaptor AC/DC | 12V / 5A DC |
| Caracteristici generale | |
| Temperatura de operare (°C) | 0°C - 50°C |
| Umiditate (%) | 20%RH - 90%RH (Equipped with SSD) |
| Sistem de operare | Windows 10 Pro 64 bit |
| Dimensiuni (mm) | 372 x 252.7 x 320 |
| Greutate (kg) | 5.86 |
| Setul conține | MSR (optional); iButton (optional); RFID (optional); Fingerprint Sensor (optional); Keypad (optional) |
